EBARA Submersible Electric Pump Loaded Water 50DVS51.5-3 2Hp 1,5kW 3x400V 50Hz

Product No.：202551984753
Online Inquiry

Ebara DVS submersible pumps use a cast iron anti-clogging semi-vortex impeller capable of pumping of foreign bodies up to 70% of the discharge outlet's diameter while retaining ease of maintenance.

The DVS electric pump is only available in a three-phase version and can be used in fixed and mobile installations.

Technical details

Model	50DVS51.5-3
Liquid Type	Loaded Water
Solid Parts Passage [Mm]	21
Voltage	3x400V 50Hz
Hp	2
Kw	1,5
Flow Rate Q [L/Min]	100÷150÷300
Head H [M]	18,8÷16,6÷10,7
Discharge	1"½
Power Cable [M]	6
Float Switch	No
Pump Body	Cast Iron
Impeller	Semi-Vortex in Cast Iron

DVS EBARA

Submersible

SUBMERSIBLE ELECTRIC PUMPS FOR LOADED WATER SEMI-VORTEX IN CAST IRON

APPLICATIONS

Effluent collection tanks
Ideal for applications with effluent containing soft or fibrous solids
Lifting or clear or grey water with suspended particles
Septic tanks (imhoff)

TECHNICAL FEATURES

Semi-vortex non-clogging impeller enables pumping of foreign matter with dimensions up to 70% of the delivery port diameter
Easy maintenance

TECHNICAL DATA

Maximum fluid temperature: 40°C
Maximum solid dimensions: 21 mm (50DVS)
33 mm (65DVS and 80DVS 1.5kW)
41 mm (65DVS and 80DVS 2.2-3.7 kW)
Maximum length of fibres: 100mm (50DVS)
200 (65DVS and 80DVS 1.5kW)
245 (65DVS and 80DVS 2-3.7 kW)
2 pole motor
Insulation class F
Protection rating IP68
Voltage:three-phase 380-415±10%, 50Hz
Flanges: G1½ (50DVS 1.5kW)
DN50, DN65, DN80
Power up to 3.7 kW

MATERIALS

Pump body, semi-vortex impeller, elbow (bend) in cast iron
Shaft made of AISI 403 stainless steel
Mechanical seal: SiC/SiC/NBR (impeller side) Carbon/Ceramic/NBR (motor side).
