Norgren V68H-NND-RMG Pressure Relief Valve

Product Description :

A pressure relief valve (PRV) is a type of safety valve designed to automatically release excess pressure from a system or vessel. Its primary purpose is to protect equipment and personnel from the hazards of overpressure. Pressure relief valves are crucial components in various industries, including oil and gas, chemical processing, power generation, and manufacturing.

• Olympian Plus pressure relief valves protect compressed air systems from over-pressurisation
• High relief capacity, sensitive and accurate
• Threaded relief port for silencer or piped exhaust



Medium	Compressed air
Operating Temperature	-20 ... 80 °C, -4 ... 176 °F
Port Size	Without Yoke
Adjustment	Adjusting screw
Maximum Inlet Pressure	20 bar, 290 psi
Outlet Pressure Adjustment	0.3 ... 10 bar, 4 ... 145 psi
Materials - Adjusting Knob	Zinc plated steel
Materials - Body	Aluminium alloy
Materials - Bonnet	Aluminium alloy
Materials - Elastomers	NBR
Dimensions - Height	232 mm
Dimensions - Length	115 mm
Dimensions - Width	91 mm
Weight	1.21 kg
Country of Origin	Czech Republic
Range	V68H
Series	Olympian Plus
Brand	IMI Norgren
